IRSAP steel tubular radiator series Tesi 6 with height 1800mm colour White Standard on Grim Network
With its six columns, TESI 6 is the version of the TESI range that provides the most heat. TESI radiators are the most functional, modular and elegant system for heating all rooms, even large ones. TESI 6 has a depth of 215 mm and different heights available. The advertisement refers to the Tesi 6 model with a height of 1800 mm, standard white colour and standard 1/2″ side connections (code 02).
Irsap radiators on Grim Network
Other construction features:
- 25 mm diameter sheet steel tubes;
- pressed sheet steel manifolds;
- maximum permissible operating pressure 8 bar
- maximum permissible operating temperature 95°C;
- Irsap valve centre distance measurement 41÷44 mm;
- Irsap lockshield centre distance measurement equal to 41÷44 mm;
- upper and lower manifold end threads 1″1/4 G right or left.
Surcharges for other finishes:
– Classic: +15%.
– Special: +25%.
– Loft treatment: +40%.
– Other Ral colours (subject to feasibility): +40%.
